| Speaker output |
|
| Rated output power |
120W + 120W (8Ω)
240W + 240W (4Ω) |
| Compatible speaker impedance |
4Ω |
| Speaer terminal |
1 set (L/R) |
| Analog audio inputs |
|
| ES-Link Analog/XLR |
3 pairs |
| Input impedance |
10kΩ (XLR) |
| RCA |
3 pairs |
| Input impedance |
10kΩ |
| PHONO |
1 pair (MM/MC switchable)
|
| Input impedance |
|
| MM |
47kΩ |
| MC |
100Ω |
| Analog audio outputs |
|
| ES-Link Analog |
1 pair |
| XLR |
1 pair |
| Output impedance |
100Ω |
| Headphone outputs |
|
| Standard 6.3mm (¼) stereo jack |
1 |
| 4-pin XLR jack |
1 |
| Maximum effective output |
|
| Unbalanced |
300mW + 300mW (into 32Ω) |
| Balanced |
600mW + 600mW (into 32Ω) |
| Applicable load impedance |
|
| Umbalanced |
16 to 600Ω |
| Balanced |
32 to 600Ω |
| Extrenal controls |
|
| RS-232C |
1 |
|
DC trigger input (TRIGGER IN) |
1 (3.5mm mono mini jack)
|
|
DC trigger output (TRIGGER OUT) |
1 (3.5mm mono mini jack)
|
| General |
|
| Power supply |
AC 100V, 50Hz/60Hz with an appropriate step-down transformer to adjust to 115~120V or 220~240V depending on market |
|
|
|
|
| Power consumption |
320W
110W (no sginal) |
| Standby power |
0.3W (when RC-232C is OFF)
0.6W (when RC-232C is ON) |
| Overall dimensions (W×H×D)
|
445 × 191 × 471mm (including protrusions) |
| Weight |
32.4kg |
| Included accessories |
Power cord × 1
Remote control (RC-1339) × 1
Batteries (AA) × 2
Felt pads × 4
Owner’s manual × 1
Warranty card × 1 |
