| Network section |
|
| Supported file formats |
|
| PCM Lossless |
FLAC, ALAC, WAV, AIFF, MQA |
| DSD Lossless |
DSF, DSDIFF (DFF) , DoP |
| Compressed audio |
MP3, AAC |
| ETHERNET port |
1 (1000BASE-T)
|
| SFP port |
1 (1000BASE-T/-LX (single mode)/-SX (multi mode))
|
|
USB DRIVE port USB2.0 or higher recommended
|
1 (TYPE-A) , 1 (TYPE-C)
|
| Supported file system |
FAT32, exFAT, NTFS, Single partation |
| Maximum current supply |
0.5A each |
| Supported sampling frequencies |
|
| PCM |
44.1 to 768kHz, 16 / 24 / 32bit
(In addition to 32-bit integer format, files that use 32-bit floating format can also be played)
|
| DSD |
2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz |
| Digital audio inputs |
|
| ES-LINK |
1 (L/R) |
| Input signal formats |
|
| Linear PCM |
44.1k to 768kHz, 48bit (ES-LINK5 format) |
| DSD |
2.8MHz, 5.6MHz, 11.2MHz, 22.4MHz (ES-LINK5 format) |
| XLR |
1 |
| Input level |
5.0Vp-p |
| Input impedance |
110Ω |
| Input signal formats |
|
| Linear PCM |
32k to 192kHz, 16 / 24bit (AES/EBU format) |
| DSD |
2.8MHz (ES-LINK1, ES-LINK2, DoP format) |
| RCA |
1 |
| Input level |
0.5Vp-p |
| Input impedance |
75Ω |
| Input signal formats |
|
| Linear PCM |
32k to 192kHz, 16 / 24bit (IEC60958 format) |
| DSD |
2.8MHz (DoP format) |
| OPTICAL |
1 |
| Input level |
–24.0 to –14.5dBm peak |
| Input signal format |
|
| Linear PCM |
32k to 192kHz, 16 / 24bit (IEC60958 format) |
| DSD |
2.8MHz (DoP format) |
| USB |
1 (TYPE-B) USB2.0 or higher recommended |
| Input signal format |
|
| Linear PCM |
44.1k to 384kHz, 16 / 24 / 32bit |
| DSD |
2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz |
| Clock sync input |
|
| BNC |
1 |
| Input impedance |
50Ω |
| Supported input frequency |
10MHz (±10ppm) |
| Input level |
|
| Rectangle wave |
TTL level, or equivalent |
| Sine wave |
0.5 to 1.0Vrms |
| External control input |
|
|
Trigger input (TRIGGER IN)
|
3.5mm mono mini jack× 1 |
| Input level |
12V, 1mA |
| Analog audio outputs |
|
| XLR/ES-Link Analog |
1 pair (L/R) |
| Maximum output level |
5.0Vrms (at 1kHz, 10kΩ load) |
| Output impedance |
50Ω |
| RCA |
1 pair (L/R) |
| Maximum output level |
2.5Vrms (at 1kHz, 10kΩ load) |
| Output impedance |
18Ω |
| Audio performance |
DSD 2.8MHz, 0dB, DSDF=F2, XLR output |
| Frequency responce |
5Hz to 30kHz (–3dB) |
| S/N ratio |
113dB (A-Weight) |
| Distortion |
0.001% (1kHz) |
| General |
|
| Power supply |
AC100V 50/60Hz |
| Power consumption |
38W (in standby: 0.3W) |
| External dimensions (W×H×D)
|
445 × 162 × 447mm / 17 ⅝” × 6 ½” × 17 ⅝” (including protrusions) |
| Weight |
27.8kg / 61 ⅜ lbs. |
| Included accessories |
Power cord × 1
Cap for DC IN terminal × 2
Owner’s manual × 1
Warranty card × 1 |
