| Network section |
|
| Supported file formats |
|
| PCM Lossless |
FLAC, ALAC, WAV, AIFF, MQA |
| DSD Lossless |
DSF, DSDIFF (DFF) , DoP |
| Compressed audio |
MP3, AAC |
| ETHERNET port |
1 (1000BASE-T)
|
| SFP port |
1 (1000BASE-T/-LX (single mode)/-SX (multi mode))
|
|
USB DRIVE port USB2.0 or higher recommended
|
1 (TYPE-A) , 1 (TYPE-C)
|
| Supported file system |
FAT32, exFAT, NTFS, Single partation |
| Maximum current supply |
0.5A each |
| Supported sampling frequencies |
|
| PCM |
44.1 to 768kHz, 16 / 24 / 32bit
(In addition to 32-bit integer format, files that use 32-bit floating format can also be played)
|
| DSD |
2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz |
| Digital outputs |
|
| ES-LINK |
× 1(L/R)
|
|
USB port (USB2.0)
|
TYPE-A × 1 (maximum current supply: 0.5A)
|
|
XLR (110Ω)
|
× 1 (PCM 44.1k〜192kHz 16/24bit、DSD 2.8MHz（DoP）)
|
|
RCA (75Ω)
|
× 1 (PCM 44.1k〜192kHz 16/24bit、DSD 2.8MHz（DoP）)
|
| Clock input |
|
| Connector |
BNC × 1 |
| Input impedance |
50Ω |
| Frequencies that can be input |
10MHz (±10ppm)
|
| Input level |
|
| Sine wave |
0.5-1.0Vrms |
| Rectangle wave |
TTL levels |
| External control |
|
|
Trigger input (TRIGGER IN)
|
3.5mm mono mini jack × 1 |
| Input level: |
12V, 1mA |
| General |
|
| Power supply |
AC100 50/60Hz
|
| Power consumption |
37 W |
| Standby power |
EU 0.35W, US 0.3W |
| External dimensions (W×H×D, including protrusions |
445 × 132 × 448mm / 17 ⅝” × 5 ¼” × 17 ¾” |
| Weight |
23.1 kg / 50 ⅞ lb |
| Included accessories |
Power cord × 1
HDMI cable × 2
Owner’s manual × 1
Warranty card × 1 |
