Input terminals (one system per terminal) |
AES/EBU |
MAX PCM 24Bit/192kHz |
COAXIAL |
MAX PCM 24Bit/192kHz |
OPTICAL |
MAX PCM 24BIT/192kHz |
USB B |
MAX PCM 32Bit 384kHz, DSD Native 256, DoP 128 (Computer or smartphone as input source with an OTG cable) |
USB A |
MAX PCM 32Bit 384kHz, DSD Native 256, DoP 128 (Computer or smartphone as input source with an OTG cable) |
Output terminals |
Balanced XLR |
MAX 4.6 Vrms |
Unbalanced RCA |
MAX 2.3 Vrms |
Others |
External dimensions |
Main body: 215mm (W) × 82mm (H) × 299mm (D) (terminals included) Power supply: 215mm (W) × 122mm (H) × 273mm (D) |
Power supply voltage |
AC100V coming with an appropriate step-down to be adjusted to 120V 220V 230V 240V of global market |
Power consumption |
30W |
Mass |
Main body 3.0kg, power supply 4.0kg |
