The Technics SB-R1 Speaker System achieves a superlative level of sound reproduction by building around the brand's linear-phase, point-sound-source concept.
The Point-Sound-Source system focuses on precise imaging through the alignment of the speaker's driver units. Wave-fronts from each unit will arrive simultaneously to the listener's ears regardless of listening position, allowing the system to sound as though there is a single sound source. The newly developed flat coaxial two-way speaker unit, combining midrange and treble drivers, works with a virtual coaxial woofer to realize a point sound source, providing smooth directional characteristics over the entire frequency range, without peaks or dips.
Phase precision Driver's offer faithful reproduction of mid to high frequency sound with an all-new flat coaxial two-way drive. A low distortion 16-cm Long Stroke Woofer is capable of reproducing super-low frequencies with a dramatic reduction in distortion, giving a powerful and dynamic bass response. Each driver is house within the high rigidity entasis form cabinet which reduces undesired resonance with a 50mm thick baffle. Combining all of these features and more, the Technics SB-R1 is a reference class speaker fit for studio and personal use.
Emotive Acoustic Technology: Point-Sound-Source Speaker System, Ultra Wide Range Reproduction, Phase Precision Driver (Coaxial Flat 2-way Speaker Unit), Low Distortion 16-cm Long Stroke Woofer, High-quality Network Circuit, High Rigidity Round Form Cabinet
Technics Definitive Design: Black high gloss piano finish, Round Form Cabinet, Magnet Fixed Fabric Grille
Type: 3.5-way 6-Speaker, Bass Reflex (including coaxial 2-way for mid-range and tweeter)
Speaker Unit: Woofer - 16 cm/6-1/2 inch Cone type x4, Midrange/Tweeter - Coaxial, 16 cm/6-1/2 inch Flat type x1 / 2.5 cm/1 inch Dome type x 1
Crossover Frequencies: 300Hz, 3kHz
Frequency Range: 20Hz - 100kHz (-16 dB), 28 Hz - 90 kHz (-10 dB)
Sound Pressure Level: 88 dB / 2.83 V (m)
Impedance: 4 ohms
Input Power (IEC): 150 W (Rated), 300 W (Max)
Dimensions (W x H x D) 408 x 1260 x 522 mm (including net and terminals) | 16-1/16 x 49-19/32 x 20-9/16 inch (including net and terminals)
Weight: Approx. 72 kg (/pc) 159 lbs. (/pc)
Accessories: Spike x 4, Spike Support x 4, Short Cable x 2, Cleaning Cloth x 1, Spacer x 4, Owner's Manual
